不銹鋼外螺紋截止閥-J21W/J23W不銹鋼外螺紋截止閥主要零件材料Materials for main parts
|
零件名稱Part name
|
閥桿、閥蓋Stem,Bonnet
|
閥桿、閥瓣Stem,Disc
|
填料Packing
|
|
J23W-16P
|
鉻鎳不銹鋼
Cr.Ni Stainless steel
|
鉻鎳不銹鋼
Cr.Ni Stainless steel
|
聚四氟乙稀、柔性石墨PTEF,Soft graphite
|
|
J23W-40、J23W-160
|
優質碳鋼
High grade carbon steel
|
鉻不銹鋼
Cr. Stainless steel
|
不銹鋼外螺紋截止閥-J21W/J23W不銹鋼外螺紋截止閥主要性能規范Chief propertyspecifieation
|
型號
Type
|
公稱壓力（MPa）Nominal pressure
|
試驗壓力PS（MPa）
Test pressure
|
工作壓力（MPa）Working pressuer
|
工作溫度（℃）Working temperature
|
適用介質Applicable mediun
|
|
殼體Shell
|
密封（液）Seal
|
密封（氣）Seal
|
|
J23W-16
|
1.6
|
2.4
|
1.76
|
0.6
|
1.6
|
P≤200℃
|
液化石油氣水、油品等Petroleun gas Water,Oil etc.
|
|
J23W-40P
|
4.0
|
6.0
|
4.4
|
0.6
|
4.0
|
|
J23W-160
|
16.0
|
17.6
|
17.6
|
0.6
|
16.0
|
C≤425℃
|
|
J23W-320P
|
32.0
|
48.0
|
35.2
|
0.6
|
32.0
|
不銹鋼外螺紋截止閥-J21W/J23W不銹鋼外螺紋截止閥主要外形及連接尺寸Main externalconnecting dimensions(mm)
|
公稱直徑（mm）Nominal diameter
|
尺 寸Dimensions
|
重量（Kg）Weight
|
|
D0
|
D1
|
D2
|
L
|
H1
|
H2
|
M
|
|
6
|
70
|
14
|
6
|
135
|
96
|
106
|
20×1.5
|
0.8
|
|
10
|
80
|
18
|
10
|
156
|
115
|
125
|
24×1.5
|
1.1
|
|
15
|
100
|
22
|
15
|
180
|
122
|
132
|
30×2
|
2.0
|
|
20
|
110
|
28
|
18
|
185
|
156
|
166
|
36×2
|
3.0
|
|
25
|
140
|
33
|
22
|
185
|
169
|
180
|
42×2
|
3.2
|
|
